(Discontinued) 30PPM A3 Mono Advanced MFD with DSPF
MXM3071

(Discontinued) 30PPM A3 Mono Advanced MFD with DSPF

Discontinued

Safe, speedy, and simple to run. The MXM3071 multi-talented monochrome MFD will be an engine of change in your office.

Copy, print, scan, or fax documents with masterful ease. Connect to cloud services and take your collaborations to the next level. Quietly efficient, the MXM3071 simply makes your office a better place to work.

POA

Multifunctional

This Sharp MFD is a printer/ copier/ scanning/ facsimile* all-in-one device. Enjoy more functions with this space-saving design.

*requires optional expansion

10.1-Inch Colour LCD Touchscreen

Sharp’s award-winning, customisable touchscreen display incorporates an Easy UI mode, for fast, simple operation, with basic functions displayed in large, clearly labelled tiles and keys. And with the Advanced Preview function, you can also check document finishes, edit pages in advance, and more.

Built-In Retractable Keyboard

Designed to simplify e-mail address and subject line entries, as well as repetitive scanning tasks and user authentication, the standard built-in keyboard offers users a familiar ergonomic interface.

Multi-Layered Security

Multi-layered, leading-edge security features provide enhanced protection and help businesses stay one step ahead of hackers and malicious network intruders. Manage your print security and protect your confidential information whether it is being printed, copied, scanned, faxed, stored, or shared over your network. The standard End-of-Lease feature can also erase all data and personal information at trade-in time.

Cloud Services

Access popular cloud services such as Microsoft® OneDrive™ for Business, SharePoint® Online, Google Drive™ , Box and Dropbox with Sharp’s Cloud Connectors. And with Sharp’s Application Portal, administrators can add or update apps directly via the MFP operation panel.

Convert Documents via OCR

With standard OCR capabilities, users can easily scan and convert documents to popular file formats including Microsoft Word, PowerPoint and Excel, as well as Searchable PDF & Encrypted PDF. Using Qualcomm DirectOffice technology, you can directly print these same file types from USB thumb drives, cloud applications and mobile devices.

Remote Operation

The Sharp Remote Operation feature lets you display the MFP’s main control panel on the screen of your PC or mobile device. From a remote location, IT Administrators and Help Desk Professionals can control the Sharp MFP and even assist users through the necessary steps when executing MFP functions.

Sharp OSA®

Sharp OSA® technology can help businesses enhance productivity, reduce costs, and simplify IT management. Utilising industry-standard protocols, Sharp MFPs can easily integrate with third-party applications directly from the operation panel. Using secure and scalable communications, Sharp OSA cloud-ready technology further expands flexibility in how the document workflow and security solutions are implemented.

Original Size
Max A3
Operation Panel
Colour 10.1" LCD Touch-Screen
Product Environment

Medium Office/Workgroup

Printed Paper Size
Tray : A3W-A5R, Bypass: A3W-A5R, Long Paper (Max. 1300mm x 320mm)
Standard Paper Capacity
650 sheets (550-sheet x 1 + 100-sheet multi bypass)
Maximum Paper Capacity
6,300 sheets (650 sheets & optional 550 + 2,100-sheet tray and 3,000-sheet LCC)
Paper Weight
Tray: 60 g/m2 to 300 g/m2. Multi-bypass tray: 55 g/m2 to 300 g/m2
Output Capacity
Opt: MXTU16 250-sheet centre tray, Opt: MXTR19N 100-sheet right tray or Finisher Option
Warm-up Time
14 sec or less (Power Button)
Resolution (Output)
9,600 (equivalent) x 600 dpi, 1200 x 1200dpi (Copy/Printer)
Memory
5 GB (STD & Max)
HDD Capacity
500GB
Duplex
Std. (60 - 256 g/m2)
Dimensions (WxDxH)
616 x 660 x 838 millimetre
Weight
72 kilogram
Sharp OSA
5.5
Copy Speed
30 ppm (A4), 15 ppm (A3)
E-Sort / SOPM
Yes / Yes
First Copy Time (OC)
4.5 Sec
Continuous Copy
Max 9,999
Scan Resolution
600 x 600 dpi, 600 x 400 dpi, 600 x 300 dpi
Zoom Range
25 - 400% (DSPF 25 - 200%) in 1% increments
Power Consumption
Max. 1.84 kW
TEC Value (Weekly)
1.7 kWh
Noise (Measured)
Operating: 52 dB, Standby 10 dB
Document Feeder
Std. DSPF
Original Capacity
Max 150 Sheets
First Copy Time
7.4 Sec
Scan Speed (Max)
Copy/Image Send Mode: 110 opm (1-sided), 220 opm (2-sided).
Quick/Main Folder
Quick Folder: Max: 10,000 pages or 1000 files, Main/ Custom: Max. 20,000 pages or 3000 files
Preview Thumbnails
Supported (includes Advanced Edit Mode)
PDL (Emulation)
STD: PCL6, Adobe® PostScript®3
Interface
USB 2.0, 10Base-T/100Base-TX/1000Base-T
Protocol
Network: TCP/ IP (IPv4, IPv6), Printing: LPR, Raw TCP (Port 9100), POP3 (email printing), HTTP, FTP for downloading print files, IPP, SMB, WSD
Supported OS
Windows® 7*, Windows® 8.1*, Windows® 10*, Windows® Server 2008* / 2008R2 / 2012 / 2012R2 / 2016 / 2019 (*32/64bit). Mac OS 10.9, 10.10, 10.11, 10.12, 10.13, 10.14 & 10.15.
Utility Software (Download)
NST-Lite; Sharpdesk with Network Scanner Tool (user license required)
Utility Software (Download)
Status Monitor
Sharpdesk Mobile
Supported
Airprint Support
Supported
Pantone Support
N/A
Resolution
Push scan: 100, 150, 200, 300, 400, 600 dpi; Pull scan 75, 100, 150, 200, 300, 400, 600 dpi (50 to 9,600 dpi via user setting)
Format
TIFF, JPEG (colour/greyscale only), XPS, PDF, PDF/A, Encrypted PDF, Searchable PDF, Compact PDF, Office Format (docx, xlsx, pptx), TXT, RTF & UTF-8.
Destination
Desktop (NST-Lite), FTP, E-Mail, SMB Folder, USB, HDD, TWAIN / WIA compliant, I-Fax (SMTP)
User Registration
Max 2,000 registrations (Max. 500 addresses for one Group Key)
Facsimile Model
Opt : MXFX15
Facsimile Model
Standard
Communication Protocol
Super G3
Transmission Speed
2 sec.range (Super G3/JBIG), 6 sec.range (G3/ECM)
Compression
MH,MR,MMR,JBIG
Inbound Routing
Yes (TIFF, XPS & PDF Format)
PC Fax
Yes (For Windows only)
