Sharp MultiSync® M322 32" Professional Large Format Display
PN-M322

Sharp MultiSync® M322 32" Professional Large Format Display

The Sharp MultiSync® M2 Series (32” up to 98”) is purpose-built for demanding signage and meeting room environments.

Featuring class-leading 450 cd/m² brightness, a high-haze panel to minimise glare, the M322 model delivers outstanding visual performance with unmatched colour precision.

Share your message, your way

The versatile solution for professional display applications, the Sharp MultiSync® M322 supports both landscape and portrait orientations while also containing a an anti-glare panel to allow for easy readability for true commercial applications. The new product contains a full metal mechanical chassis, allowing for a more robust design necessary for commercial applications while maintaining the attractive aesthetics that allow the focus of onlookers to be on what matters – the message.

Simple and targeted connectivity options allow customers to have the up-to-date options that they need while not having to overpay for excess and unused interfaces. Ideal for a majority of digital signage applications in corporate, higher education, restaurant, retail and grocery store environments when the focus should be on the message, not the budget.

Benefits

  • Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
  • Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C
  • 450 cd/m2 brightness and HDR compatibility will capture the attention of audience in almost any situation
  • Integrated Media Player allows for audio, video or image playback via USB
  • Failover Capabilities with full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails
  • NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations
Panel Technology
VA
Active Screen Area
698.4 x 392.9mm
Screen Size
32 inch
Aspect Ratio
16:9
Pixel Pitch
0.364 mm
Brightness
450 cd/m2
Contrast Ratio
4000:1
Viewing Angle (H/V)
178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Colour Depth [bn]
More than 16.7 million
Colour Gamut
72% of NTSC
Response Time
8ms
Panel Refresh Rate (Hz)
60Hz
Haze Level (%)
25
Supported Orientation
Landscape, Portrait
Native Resolution
3840 x 2160
Supported Resolution
1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1360 x 768; 1366 x 768; 1400 x 1050; 1440 x 900; 1600 x 1200; 1680 x 1050; 1920 x 1080; 1920 x 1200; 1920 x 1200; 1920 x 2160; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 400; 720 x 480;
Horizontal Frequency [kHz]
15 - 135
Vertical Frequency [Hz]
23-76
HDMI IN 1
Video Input; UHD (60 Hz) HDCP (2.2); Audio Input; ARC; CEC
HDMI IN 2
Video Input; UHD (60 Hz) HDCP (2.2); Audio Input; CEC
DP IN 1
Video Input; UHD (60 Hz) DP 1.2; HDCP (2.2); Audio Input
USB-A 1
USB 2.0 / 3.2; 4.5 W; Peripherals; USB Storage
Audio Output (3.5 mm)
Audio Output; Line Out
LAN 1
100 MBit/s
RS-232C
9600 bps
Ambient Light Sensor
optional via Eco Sensor (PNKTES1)
Temperature Sensor
Integrated, 3 sensors, triggered actions programmable
Human Sensor
optional via Eco Sensor (PNKTES1)
Power Consumption
40W shipping
Power Savings Mode
< 0.5; < 2 (Networked Standby)
Power Supply
100-240 V AC; 50/60 Hz; internal
Operating Temperature
0ºC to 40ºC
Operating Humidity
20% to 80%
Storage Temperature
-20ºC to 60ºC
Storage Humidity
10% to 80%
Dimensions (W x H x D) [mm]
726.5 x 425.4 x 66.5
Dimensions (W x H x D) [mm]
870.0 x 527.0 x 160.0
Weight [kg]
6.3
VESA Mounting [mm]
100x100mm, 200x200mm (off-center)
Bezel Width [mm]
11.9 (left and right); 11.8 (top); 17.2 (bottom)
Packaging Weight [kg]
9.8
Material
Metal
Accessories
Eco Sensor (PNKTES1); Soundbar (PN-ZCMS1)
Safety and Ergonomics
CE; RCM; EMC Class B; Energy Star 8; FCC Class B; REACH; RoHS; UKCA; UL/C-UL or CSA
Additional Features

AMX Support, Automated Email Alert Function, CEC Support through HDMI, Crestron Roomview Support, Display Browser Control, Display Wall Calibrator Compatible, HDR Compatible (PQ, HLG, HDR10), Key Guide, NaViSet Administrator 2 Compatible, OSD Rotation for Portrait Orientation, PJ Link Support, Power USB Port (5V/2A), Removeable Logo Ornament, Real Time Clock, TileMatrix, SNMP, Consumer Electronics Control (CEC), Integrated USB Media Player, Integrated Temperature sensor, Full Input Detect Functionality, Programmable Gamma, Scheduler Function, Off Timer, Vacation Switch, Variable or Fixed Audio Out, Key and Button Lock Settings, USB Copy

Colour Versions
Black Front Bezel, Black Back Cabinet
Audio (Speakers)
Integrated Speakers (5W + 5W)
Shipping Content (Accessories)
3m AC Power Cord, 2.0m HDMI Cable, IR Remote Control, AAA batteries
Operating Hours
24/7
Remote Management
NaViSet Administrator 2
